Description
BDS corrects steering geometry at the new taller ride height using a pair of high-strength CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.
Specifications:
| Description_ASC | Fits 4WD models only |
| Description_ASC | RAMs with factory 22″ wheels require larger bore knuckles due to larger wheel bearing assembly. Reference build code WPM or WPZ. |
| Description_ASC | Stock 18″ wheels cannot be reinstalled due to steering interference. Stock 20s can be reinstalled with factory tire size |
| Description_ASC | Vehicles equipped with the Off-Road Group Package require the Ram 1500 Rebel 4in kit to achieve correct ride height. To find out if your truck is equipped with the Off-Road Group call your local Ram dealer provide your VIN and ask if they can pull your window sticker. In the ‘Optional Equipment’ section there will be a line item that reads ‘Off-Road Group’ if your truck is equipped. |
| Description_ASC | Will NOT fit 2019-2022 RAM 1500 Classic models Refer to the 2018 kit listings. |
| Description_ASC | Will NOT fit adjustable “air ride” suspension equipped models. |
| Description_ASC | Will NOT fit models equipped with the Thermal Axle option. Reference build code DSK-P or check the diff cover for cooling lines. |
| Description_ASC | Will NOT work on diesel models |
| Description_DEF | Suspension Lift Kit |
| Description_DES | 2019-2022 Ram 1500 4wd 4in. front shocks| – FOX |
| Description_EXT | 2019-2022 Ram 1500 3in Rear Coil Box Kit |
| Description_EXT | 2019-2022 Ram 1500 4in Strut Spacer Box Kit |
| Description_EXT | 2019-2022 Ram 1500 4wd 4in. front shocks| 3in. rear block – FOX |
| Description_EXT | 2019-2022 Ram 1500 Knuckle Box Kit – DRV |
| Description_EXT | 2019-2022 Ram 1500 Knuckle Box Kit – PASS |
| Description_EXT | 2019-2022 Ram 1500 Rear Box Kit |
| Description_EXT | 2019-2022 Ram Front Box Kit 1 of 2 |
| Description_EXT | 2019-2022 Ram Front Box Kit 2 of 2 |
| Description_EXT | Fox 2.0 Shock 28.25 x 17.15 x 2- S50/EB1 |
| Description_FAB | BDS NX2 gas or FOX performance series IFP gas shocks to improved ride and offroad performance |
| Description_FAB | Factory Protection Plus drivetrain warranty included |
| Description_FAB | HD skid plate system improved offroad protection |
| Description_FAB | High clearance crossmember design maximizes ground clearance |
| Description_FAB | Multipoint differential relocation brackets to secure the front axle and improve CV angles |
| Description_FAB | Robust steering knuckles maintain ESC system compliance |
| Description_MKT | BDS corrects steering geometry at the new taller ride height using a pair of high-strength CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility. |
| Description_MKT | BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection. |
| Description_MKT | BDS steps up the performance and capability of the 2019-2023 RAM 1500 trucks with a 4-inch suspension lift kit. Designed to improve stance performance and capability this kit includes everything necessary to set your truck up right with clearance for up to 35″ tires |
| Description_MKT | Heavy Duty Steering Knuckles |
| Description_MKT | High Clearance Crossmembers |
| Description_MKT | In the rear this kit utilizes progressive rate Pro-Ride coil springs rear upper control arm relocation brackets to correct pinion angle track bar relocation bracket to correct axle positioning bump stop extensions and sway bar links. The rear of these kits are rounded out with your choice of specially tuned NX2 nitro series gas shocks or FOX 2.0 IFP performance series gas shocks to offer improved damper performance. |
| Description_MKT | This kit takes advantage of BDS’s tried and true high-clearance design for improved ground clearance strength and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics. Up front the kit utilizes top mounted strut spacers high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection. Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles and replacement tie rod ends allowing for ESC system compatibility. These combined with the provided sway bar drops bump stop extensions stainless steel braided brake lines CV spacers supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it. |
| Description_SHO | Suspension lift kit |
